SENTOP RP7S-630 NEW
High-Capacity Dual Power ATS | Integrated MCCB Class Protection
High-Performance Industrial Power Transfer
The SENTOP RP7S-630 NEW is a sophisticated CB-class automatic transfer switch that combines the functions of two molded case circuit breakers (MCCB) with an advanced electronic control unit. Designed for large-scale power distribution systems, it provides essential overload and short-circuit protection while managing the transition between primary and backup power sources. The “NEW” series features enhanced mechanical interlocking and optimized electronic logic, ensuring that high-current loads are transferred safely and reliably in factories, commercial complexes, and data centers.
Technical Specifications
| Technical Parameter | RP7S-630 NEW Data |
|---|---|
| ATS Class | CB Class (MCCB Based) |
| Rated Current (In) | 400A, 500A, 630A (Full Series 16A-630A) |
| Number of Poles | 3P / 4P |
| Rated Working Voltage (Ue) | AC 400V / 415V |
| Rated Insulation Voltage (Ui) | 800V |
| Rated Impulse Voltage (Uimp) | 8kV |
| Short-circuit Breaking Capacity (Icu) | 35kA / 50kA |
| Transfer Time | ≤ 2.0s (Adjustable monitoring delay) |
| Operation Mode | Automatic / Manual / Remote Control |
| Mechanical Life | Over 5,000 Operations |
| Standards | IEC/EN 60947-6-1, GB/T 14048.11 |
Superior Protection Features
- Dual-MCCB Architecture: Provides true short-circuit and thermal overload protection on both power paths.
- Safe Mechanical Interlock: High-strength steel interlocking frame prevents simultaneous connection of both sources.
- Fire Control Linkage: Supports remote emergency tripping for building fire safety integration.
Advanced Intelligence
- Smart Voltage Monitoring: Detects phase loss, under-voltage, and over-voltage with precision.
- Customizable Delays: Adjustable transfer and return delay times to accommodate grid stability issues.
- LCD/LED Interface: Clear status indication for easy troubleshooting and maintenance.
Industry Applications
🏭 Heavy Industry
Reliable power switching for large-scale production lines and smelting facilities.
🏢 Urban Infrastructure
Standard dual-power solution for high-rise commercial buildings and malls.
🏥 Critical Facilities
Guarantees uninterruptible power for hospitals and Tier 3 data centers.
Bulk Pricing or Custom Engineering Support?
SENTOP provides professional technical guidance and high-volume wholesale pricing for the RP7S NEW high-capacity range.
