SENTOP RP6-63R Series
Mini Automatic Transfer Switch (ATS) | Dual Power Reliability
Product Overview
The SENTOP RP6-63R is a high-performance, mini-type dual power automatic transfer switch designed for AC 50/60Hz power systems. It is primarily used to test whether the main power or backup power is normal, ensuring the continuity, reliability, and safety of the power supply. When the normal power is abnormal, the backup power takes over immediately to ensure uninterrupted service. Ideal for residential applications, high-rise buildings, and industrial control panels, it supports both automatic and manual operation modes.
Technical Specifications
| Parameter Description | Technical Data |
|---|---|
| Model Number | RP6-63R |
| Rated Current (Ie) | 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A |
| Number of Poles | 2P / 3P / 4P |
| Rated Working Voltage (Ue) | AC 230V (2P) / AC 400V (3P/4P) |
| Rated Insulation Voltage (Ui) | 690V |
| Rated Frequency | 50 / 60Hz |
| ATS Class | PC Class (Non-fused) |
| Transfer Time | ≤ 50ms |
| Mechanical Life | 5,000 Times |
| Electrical Life | 2,000 Times |
| Standard | IEC / EN 60947-6-1 |
| Mounting Method | 35mm DIN Rail / Screw Fixed |
Key Features
- Rapid Response: Millisecond switching ensures that electronic equipment does not restart during power failure.
- Dual Control: Easily switch between Automatic mode (priority to main power) and Manual mode for maintenance.
- Safe Isolation: PC-class construction provides excellent arc extinguishing and isolation performance.
- Signal Outputs: Features built-in auxiliary contacts for remote status monitoring.
Robust Construction
- Flame Retardant Housing: High-strength plastic casing prevents fire hazards.
- Silver Alloy Contacts: Premium contact material for long electrical life and low temperature rise.
- Modular Design: Compact 4P width fits easily into standard distribution boards.
Industry Applications
🏠 Smart Home
Essential for uninterruptible power for smart home hubs, security, and lighting.
🏭 Industrial Panels
Provides emergency backup power for PLC controllers and critical production sensors.
🏥 Healthcare Facilities
Reliable power switching for clinics, pharmacies, and small medical laboratories.
Request a Specialized Quote for ATS Series
SENTOP provides professional technical support and bulk wholesale pricing for the RP6-63R ATS range.
