Dual power automatic transfer switch
Employing double row composite contacts, horizontal direction pulling mechanism, permanent magnet synchronous motor pre storage, and microelectronic control technology, it is devoid of the requirement of an arc extinguishing cover and offers near zero arcing.
Employing dependable mechanical and electrical interlocking mechanisms.
It uses zero return technology (double shunt), and has the capability of switching to zero position simultaneously in case of emergencies (cutting off two power supplies), and there are apparent switch indicators, padlocks, etc., for safe isolation between the power supply and the load.
High reliability, the service life more than 8000 times; Integrated structure, precise, flexible, and smooth conversion of switch; Excellent electromagnetic compatibility, outstanding anti-interference ability, and not affected by external interference; High degree of automation.
There are several input/output interfaces provided in this switch, which supports remote PLC control and automation of the system.
Specification of dual power automatic transfer switch
| Place of Origin | Zhejiang, China |
| Brand Name | ONESTOP |
| Model Number | ACS |
| Product name | Automatic Transfer Switch ATS |
| Type | PC, 1-0-ll. Auto |
| Rated working voltage | AC 400V |
| Rated control voltage | AC 220V |
| Rated frequency | 50/60Hz |
| Conform standard | IEC60947-6-1 |
| Operation type | Manual or Auto |
| Indicator | With Indicate light for Main power, and standbypower. |
| Pole | 3/4 Pole |
WHY CHOOSE US
The most popular product
Our double power automatic transfer switch has won wide reputation and popularity of customers worldwide owing to its excellent quality and reasonable price. We promise to provide a 2-year guarantee service and all-round after-sales technical support in order to allow our customers to have long-term stable usage and operational experience of the equipment.
