Solar grid connected inverter with intelligent monitoring
This high-quality 5kVA solar grid connected inverter features an IP65 protection design and is equipped with an aluminum casing to ensure excellent durability and protection performance. Built in LED LCD screen provides a clear operating interface, and also has intelligent monitoring function, which facilitates real-time monitoring and management of the operation status of the solar energy system.
1. Maximum efficiency of 98.2%
2. Series current of 13A, compatible with high-power modules
3.150% photovoltaic configuration, 110% output overload
4. IP65 waterproof and dustproof, C5 anti-corrosion
5. Compatible with wide grid voltage and high-order harmonic grid environment
6. DC/AC SPD optional, AFCI detection optional
7. Remote configuration and upgrade
8. Support export power control
Parameter specifications
| Model | OST 5000 HB-60 | OST 5000 HB-120 | OST 6000 HB-120 |
| Max.effificiency(PV to AC) | 97.3% | ||
| Max.effificiency (BAT to AC) | 94.0% | ||
| Max. PV Power | 9000W | ||
| Max PV voltage | 550V | ||
| Max input current (input A/input B) | 15A/15A | ||
| Max short current (input A/input B) | 20A/20A | ||
| Start operating voltage | 90V | ||
| No.of MPPT trackers | 2 | ||
| Max. charge/discharge current | 60A/60A | 120A/120A | 120A/120A |
| Nominal AC output power | 5000W | 5000W | 6000W |
| Rated AC voltage | 220V | ||
| AC voltage range | 150V-300V (Adjustable) | ||
| Grid connection | Single phase | ||
| Noise emission | <35dB | ||
| Ingress protection degree | IP65 | ||
| Cooling concept | Natural Cooling | ||
| Dimensions (W*H*D) | 515mm*485mm*175mm | ||
| Display | LED+APP | ||
| Certification | IEC 61000-1/2/3/4, G99, NRS 097, EN 50549-1, IEC 61727/62116, CEI 021 | ||
| Warranty | 5 Years / 10 Years (Optional) | ||
Efficient effect
The function of a solar grid connected inverter is to convert the direct current (DC) generated by solar panels into alternating current (AC), thereby rendering it compatible to be plugged into the grid and integrated into the power system. Inverters not only ensure the conversion efficiency of current, but also monitor and ensure the safety of the system, against overload, overvoltage and other faults, and ensure the stable operation of solar power generation systems. In addition, the inverter can also adjust the output power to ensure synchronization with the grid and improve the energy utilization efficiency of the entire system
WHY CHOOSE US
The feedback from customers reflects their high trust in our products, and their repeated purchases indicate that our product quality and performance have been widely recognized. With the guarantee of professional installation by workers, the solar inverter has successfully started, achieving efficient energy conversion and fully leveraging its important role in clean energy utilization, bringing stable and reliable power supply to users.
ONESTOP is a top-rated solar inverter manufacturer in China, and through advanced technology and excellent quality, we have earned an excellent reputation in the industry. We have established cooperation with a number of Fortune 500 companies, fully demonstrating our technological strength and market competitiveness. Our products are renowned for their excellent performance, stability, and high efficiency, and are being used widely around the world to promote the popularization and sustainable development of clean energy.
