275V SPD 1P+N surge protector
The new integrated surge backup protector integrates circuit breaker function and power frequency continuous current protection, supports 35mm rail installation, adapts to AC 50/60Hz, rated voltage 275V, and protection level up to IP20, suitable for complex industrial environments
SPD has a nanosecond response speed, which can quickly suppress surge voltage in a very short time, effectively protecting sensitive equipment from damage. At the same time, it can also absorb and divert high-energy surge currents, prevent equipment from being subjected to high voltage shocks, ensure stable system operation, and enhance overall safety.
Parameter specifications
| Place of Origin | Zhejiang, China |
| Brand Name | ONESTOP |
| Model Number | BY7-20/2-275 |
| Type of network systems | TN-S,TN-C-S,IT |
| Maximum continuous voltage | 275V |
| Maximum discharge surge current | 20kA |
| Norminal discharge voltage | 10kA |
| Voltage protection leve! | 1.0kV |
| Protection Level | IP20 |
| Certificate | CE,CB,TUV |
We are a factory
Being a direct factory supplier, we directly manage all the production procedures to ensure stable quality. From raw material procurement to production and manufacturing, the entire process is in accordance with the ISO quality management system and strictly follows standardized operation.
All the key raw materials are UL certified to ensure product safety and reliability. Under the enhanced quality control, customers are provided with high-quality and highly stable surge protectors to ensure the long-term stable running of our products.
